详细信息
上海赵迪生物科技有限公司,为国内各大企业提供优质价廉的医疗产品和医疗产品服务,得到了全国企业事业和医疗相关部门的肯定和嘉奖。竭诚欢迎中外客商光临惠顾!
产品特性
1微电脑控制,触摸面板,LCD、LED双显示,运行参数可自动记忆,可RCF直接启动,方便操作使用
Microprocessor control, operated by touch panel, visual digital display, operated data can automatic memory, RCF value can be set directly for working and convenient use./convenient operation.
2大力矩无刷变频电机驱动,欧洲进口超高速轴承,运行平稳,免维护
Brushless converter motor which has high torque, Imported super speed bearing from Europe, smooth running and maintenance free.
3多层减振结构,欧洲进口无氟压缩机组,振动小、噪声低,环保
Multi-storey damping system, the compressor imported from Europe operating without Freon, it is running with low noise and slight vibration and green/environment protection.
4钢制机身,不锈钢离心腔,关键件进口,易清洁,耐用
Vertical and steel body, stainless steel centrifugal chamber, key components are imported, easy to clean and durable.
5转子识别系统,超温、超速、门盖、不平衡等保护功能,主机及转子寿命计算功能,确保安全
The function of rotor identity System, overspeed, overtemperature, door interlock, strap broken protection. The function of service life calculation, ensure safety.
6离心腔预冷设计,降温快;专有的SCT转速控制技术,升降速快,省时高效
The function of inner chamber pre-cooling, faster Temprature drop.Proprietary/particular SCT speed control design,he speed of raising or reducing can be faster, time saving and high effect.
7、0-9档10种升降速率选择或直接输入升降速时间,可存储40种自定义工作模式,实现***优化离心
Adjustable rise-and-decrease speed from grade 0 to 9 or directly set the time of acceleration and deceleration, and can be store 40 kinds of self-defining operating models to achieve the best results.
8独特的SBT控制技术和转子设计,减少重悬,确保样品的***大得率
Proprietary/particular SBT control technique and rotor design,to avoid mix up,ensure maximum separating effect.
9点动功能,短暂离心,便于多样化离心
Hold-on and transient centrifuging.
10既能大容量离心又能高速离心,一机多用,广泛应用于研究和生产
Not only big capacity but high speed as well/Both big capacity and high speed, is a multi-purpose machine, widely used in research and production.
技术参数TECHNICAL PARAMETER
|
型号 Model |
GL10MA |
|
***高转速 Max Speed |
10000r/min |
|
***大相对离心力 Max Rcf |
18300×g |
|
***大容量 Max Capacity |
6000ml |
|
转速精度 Speed Accuracy |
±20r/min |
|
温控范围 Temperature Range |
|
|
温控精度 Temperature Accuracy |
± |
|
定时范围 Time Range |
0-99H59min |
|
电源 Power Supply |
AC 220V 50Hz 35A |
|
整机噪声 Noise |
≤65dB |
|
外形尺寸 Dimension |
830×720× |
|
重量 Weight |
|
转子 Rotor
|
转子类型 Model |
转子号 Number |
容量 Capacity |
***高转速 Max Speed |
***大相对离心力 Max Rcf |
试管尺寸(mm) Dimension of Tube |
|
角转子 Angle Rotor |
No.29 |
6×300ml |
10000 r/min |
18300×g |
Φ62×139 |
|
No.33 |
6×500ml |
8000 r/min |
11680×g |
Φ74×168 |
|
|
No.36 |
6×1000ml |
7200 r/min |
12166×g |
Φ97×175 |
|
|
水平转子 Swing Rotor |
No.65 |
6×1000ml(圆杯) (roundness bucket) |
4200 r/min |
5100×g |
Φ100×175 |
|
6×1000ml(方杯) (rectangle bucket) |
4200 r/min |
5100×g |
血站专用 special for blood bag/bank |
||
|
No.66 |
4×1000ml |
4200 r/min |
4430×g |
Φ100×175 |
报价表
|
序号 |
产品名称 |
型号 |
容量 |
***高转速(r/min) |
***大离心力(×g) |
价格(元) |
|||
|
高速大容量冷冻离心机 |
GL10M |
6000ml |
10000 |
18300 |
84800 |
|
|||
|
角转子 |
No.36 |
6×1000ml |
7200 |
12166 |
28000 |
|
|||
|
No.29 |
6×300ml |
10000 |
18300 |
12800 |
|
||||
|
No.33 |
6×500ml |
8000 |
11680 |
13800 |
|
||||
|
水平转子 |
No.65 |
6×1000ml(圆杯) |
4200 |
5100 |
14800 |
|
|||
|
6×1000ml(方杯) |
4200 |
5100 |
18800 |
|
|||||
|
No.66 |
4×1000ml |
4200 |
4430 |
10000 |
|
||||
此报价为市场价,且不包括转子的价格,具体的价格您可以与我们在线客服或销售人员联系!我们竭诚欢迎您的惠顾!
